48F Single Mode Fiber Optic Pigtail LSZH SC/APC Connectors

Product Categories
Optic River Communication Ltd
Contact Now

48F Single Mode Fiber Optic Pigtail LSZH SC/APC Connectors

  • 1
  • 2

Brand Name : OEM

Model Number : SC/APC-48F-M-6.0-L-15M

Certification : ISO9001

Place of Origin : CHINA

MOQ : Support sample order

Price : Negotiation

Payment Terms : T/T, Western Union, L/C

Supply Ability : 1000,000 connectors/month

Delivery Time : 3-7 work days

Packaging Details : Individual packaging with Ziplock Bag

Fiber Type : G.657A2

Jacket Material : LSZH

Fiber Count : 48 Fibers

Polishing : APC

Jacket Color : Yellow

Connector Style : SC/APC

Warranty : 1 year

Boot color : Green

Breakout tube length : 0.5M

Contact Now

Distribution Fiber Optic Cable 48F Single Mode Fibers With SC/APC Connectors And Pulling Eye

The distribution bundled pigtail fiber, also known as the tail fiber bundle, has a connector at one end and a broken end of the fiber cable at the other end. It is connected to the core of other fiber optic cables by splicing, and is often installed to connect terminal equipment in the ODF frame box, fiber terminal box. There is an added black net at the connector side to protect the connectors and is shaped into a pulling eye which plays an important part when construction.







Product information

Connector type SC/APC Fiber count 48
Fiber number 2 Fiber mode 9/125μm G.657A2
Wavelength 1310/155nm Connector material Plastic housing and boot
Insertion loss <=0.3dB Breakout length 0.5M
Fiber grade Bend insensitive Return loss ≥60dB
Cable jacket material LSZH/PVC Cable diameter  6.0mm mini cable
Vibration ≤0.2dB Operating temperature -20-+60℃

Features

◆ Singlemode or Multimode cable
◆ From 6 fibers to 48 fibers
◆ With SC, ST, FC, LC, MTRJ, or E2000 connector
◆ Fiber type available: OS1, OS2, OM1, OM2, OM3, OM4, OM5
◆ Low insertion loss and high return loss
◆100% inspected for optical characteristics before shipment

Applications

◆ Equipment to equipment patching
◆ Epon/Gpon passive optical network

◆ Termination enclosure for equipment patching

◆ Fiber to the x, Fiber to the building

◆ Backbone application in building
◆ Active device termination

Drawing and cable length tolerance

Length Tolerance
L<1M ±0.08M
1M≤L<20M ±0.10M
L≥20M ±1%M
